NEW ! SUPER STUDY BOAT PLANS ... Delivered by DOWNLOAD to your computer within 12 hours of you placing your order.
The study plans have lists of materials & equipment etc & these will be useful in costing out the complete boat. Each STUDY PLAN contains ALL the construction drawings for FIBERGLASS as applicable to the particular boat plan - with up to 25 sheets per plan!  Lists of materials - Technical information - Numerous construction drawings are all included. You can view & print the drawings in full or in sections. BUILDING PHOTOS are included in the study plan package. e-book BUILD YOUR OWN (Sail or Power) BOAT you receive a FREE ( VALUE £69.00 )



e-book BUILD YOUR OWN BOAT .. + STEP BY STEP BOAT BUILDING PHOTOS - STUDY PLAN CAT 39+400 +CAT 46-465-470 All versions..  £59.95 - us$94.75 - €84.75 - When you use your credit or debit card you will be charged at the correct exchange rate in your own currency.

STEP BY STEP ASSEMBLY PHOTOS INCLUDED WITH THE STUDY PLANS & COMPLETE PLANS

SPECIAL INTRODUCTORY OFFER: COMPLETE BOAT PLANS & FULL SIZE FRAME PATTERNS ... Delivered by DOWNLOAD to your computer within 12 hours of you placing your order.
  The plans have all the information you need to build your own boat.. Each plan contains all the drawings for FIBERGLASS construction, plus bonus drawings covering electrical, plumbing and engineering, everything you need to build your boat. Plus you will receive a DETAIL FOLIO showing how to make many of your own boat fittings, lists of materials and equipment are all included plus all technical information, numerous construction drawings and written building instructions are all included. You can view & print the drawings in full or in sections. BUILDING PHOTOS are included in the plan package. PLUS you receive a FREE ( VALUE £69.00 )



e-book BUILD YOUR OWN SAILBOAT .. Only available at this price if you order off this page ....


COMPLETE PLANS & PATTERNS  CAT 46 / 470  £795 - $1,125 - €1,049

CATAMARAN 465/ 46 /470

FIBERGLASS POWER / CATAMARAN  or  POWER SAILER

ALSO SEE:  ALL CATAMARAN BOAT PLANS & STEEL OR ALUMINUM PLANS & CUTTING FILES

The CATAMARAN 46 was designed to be built using the fibreglass panel construction techniques. The method is very simple to use and perfect for the inexperienced builder.

All of the development is done in the computer and patterns are supplied for the female frame formers. Special pre-scaled drawings are supplied for each hull panel making it simple for the builder to laminate all of the hull and superstructure on a flat table. The panels are set inside the pre-erected framework and laminated together similar to the plywood Stitch and Glue method.

This CATAMARAN can be built with or without a fly-bridge


Plans & mould patterns for FIBERGLASS construction. This boat is a true power CATAMARAN capable of 30 knots under reasonable power.

Designed to be built using the fibreglass panel construction techniques; the method is very simple to use and perfect for the inexperienced builder.

Lots of deck area make this an ideal boat for taking out parties who want to enjoy the sunshine.

The profile drawing shown here reveals the clean lines of this boat.

The accommodation plan may be varied to suit your requirements - this is an easy boat to build and the STUDY boat plans on DOWNLOAD or on USB
or the Complete boat plans and frame patterns make the construction easy to understand and execute.

Several of our power cat designs are suitable for use as Sport Fisherman.  The Cat 35 (Fiberglass), Cat 39 (fiberglass or aluminum) Cat 46 (Fiberglass) are all suitable for this use.

Email Bruce for additional information.

STUDY PLAN PACKAGES ON DOWNLOAD or on USB
- GIVE ACCESS TO MANY step by step BOAT  CONSTRUCTION PHOTOS + PHOTOS OF COMPLETED BOATS ETC. SEE DETAILS
